POWER SUPPLIES

Power supply: AC100-240V,50/60Hz

Power Consumption:   350W

LIGHT SOURCE

Lamp:     1pcs COB   250W white LEDS

Oerage lifetime:   5000 hours

OPTICS

Prism: 8-facet prism & adjustable rotation speed & double direction rotation

Gobo rotation at double direction rotation

Focus: motorized   focus

Beam angle: 5.5°-30°

High brightness output, 13300LUX@5M at White light

Ballast:    Electronic Ballast

CONTROL& PROGRAM

Protocol: USITT DMX-512, Wireless, Auto/Master/Slaveoperation, stand alone operation

Display: LCD control panel with setting and addressing function customized

Data in/out: Locking 3-pin and 5 pin

Power connection: PowerCon in and out

FUNCTION

Color Wheel: 7 colors +white,

· 1 static Gobo Wheel: 8 gobos +white

· 1 Rotate Gobo Wheel: 7gobos +white, wheel rotation and shake

strobe from fast to slow, speed adjusted
electronical dimmer 0-100%

DMX CHANNEL

16/18

.

MOVEMENT

PAN = 540°

TILT= 270°
