POWER SUPPLIES

Power supply: AC100-240V,50/60Hz

LAMP SOURCE

Lamp:     YODN MSD 350W R17, CRI75

Oerage lifetime: 1500h

OPTICS

3 lens type high quality lens group

Focus: Motorize focus

Ballast:    Electronic Ballast

CONTROL& PROGRAM

Protocol: USITT DMX-512,Auto/Master/Slaveoperation, stand alone operation

Display: LCD control panel with setting andaddressing function customized

Data in/out: Waterproof  connection cables

Power connection: Waterproof  connection cables

FUNCTION

Color wheel:  14 dichroic filters + white

Gobo wheels:  17 fixed gobo + white

Prism:

Prism : 8-facet circular prism rotating inboth directions at different speeds,  16 facet prism and 24 facet prism are available for choosing.

Stroboscopic：A mechanical shutter speed stroboscopic effect

Dimmer：Full range dimming

Frost : separate, variable

DMX CHANNEL:16

.

MOVEMENT

PAN = 540°

TILT= 270°

BODY

Size: 590×650×920 mm

N.W. : 35KG

PACKING

Cartons

Flightcase（Roadcase） 1 for 1

Customized packing is available

AVAILABLE ACCESSORIE (Rigging)

Safe cables

Clamps

2 x Omega bracket with ¼-turn quicklocks
