POWER SUPPLIES

Power supply: AC100-240V,50/60Hz

Power consumption:      200W

Out put: 450VA

LAMP SOURCE

Lamp:     19*15W OSRAM Ostar RGBW LEDS

Lamp Average lifetime: 5,000 h

Color temperature：2500 - 8000 k

OPTICS

4°-60° Electronic Zoom Range

2000 LUX at 2 meter for Maximum beam angel 60°

22600 LUX at 2 meter for Maximum beam angel 4°

CONTROL& PROGRAM

Protocol: USITT DMX-512,Auto/Master/Slaveoperation, stand alone operation

Display: LCD control panel with setting andaddressing function customized

Data in/out: Locking 3-pin and 5-pin  XLR

Powercon In and out

FUNCTION

There kind effects

Uniform wash,mid-air parallel beam,fantastic built-in graphic effects

Three operating modes: wash, beam, FX(Kaleido effects)

Front Lens dual-directional Rotation

Digital Wash-Beam Framing effect

Beam edge softening control (in Wash mode)

0-100% linear electronic dimmer

Adjustable speed stop/strobe effect, withinstantaneous blackout

RGBW auto-tuning

Individual Led control

dynamiceffect.

DMX CHANNEL

21channels. 35Channels

.

BODY

Size: 500×370×250mm/ 19.68"x14.56"x9.84"

N.W. : 15KG

G. W. 16KG

MOVEMENT

3 phase motor

PAN = 540°

TILT = 270°

PACKING

Cartons

Flightcase（Roadcase）1 for2,, 1 for 1, 1 for 4

Customized packing is available

AVAILABLE ACCESSORIES

Safe cables

Clamps

Quick locks
