POWER SUPPLIES

Power supply: AC100-240V,50/60Hz

Power consumption: 160W

LAMP SOURCE

Lamp:     1pcs COB  90W white LEDS

Oerage lifetime:  5000 hours

OPTICS

Prism: 3-facet prism & adjustable rotation speed & double direction rotation

Gobo rotation at double direction rotation

Focus: motorized  focus

Ballast:    Electronic Ballast

CONTROL& PROGRAM

Protocol: USITT DMX-512,Auto/Master/Slaveoperation, stand alone operation

Display: LCD control panel with setting and addressing function customized

Data in/out: Locking 3-pin

Power connection: IEC

FUNCTION

COLOR WHEEL

1 color wheel, 7 color plus white, rainbow effect

GOBO WHEEL

1fixed gobo wheel, 8gobos plus white

1 gobo wheel, 6 gobo plus white, gobo rotating 360 degree
strobe from fast to slow, speed adjusted
electronical dimmer 0-100%

DMX CHANNEL

16

.

MOVEMENT

PAN = 540°

TILT= 270°

BODY

Size: 360x340x320mm/ 14.17"x13.59"x12.59"

N.W. : 7KG

G. W.  8KG

PACKING

Cartons

Flightcase（Roadcase）1 for 2,, 1 for 1, 1 for 4

Customized packing is available

AVAILABLE ACCESSORIE (Rigging)

Safe cables

Clamps

Mounting parts:
